Valve Categories
Saddle Clamp
DN
50~300 (2"~12")
PN
1.0~1.6
Temperature Range
-10°C~110°C
Connection
Coupling
Installation Direction
Bidirectional
Coating
EN30677
Pipe
GB/T13663, ISO4427
Inspection
EN12266
Body Materials
GGG40, GGG50
Fasteners Materials
Galvanized steel, 201, 304, 316, Dacromet
Coating Materials
Standard, WRAS
Sealing Materials
NBR, EPDM
Features & Benefits
Saddle Clamp is a fitting used for pipeline repair, suitable for pipes of various materials such as ductile iron pipes, cement pipes, cast iron pipes, fiberglass pipes, PE pipes, PVC pipes, galvanized pipes, etc. This joint design enables it to perform rapid device repairs in the event of porosity, sand holes, cracks, loose joints, damaged rubber rings, aging, and other issues in the pipeline.
Industry Options
| Materials | Characteristics | Low Temp. ℃ | High Temp. ℃ | Recommended ℃ |
| NBR | Oil resistivity | -30 | 100 | -15~90 |
| EPDM | Aging resistance, ozone resistance, corrosion resistance | -40 | 125 | -25~110 |
| HT EPDM | Aging resistance, ozone resistance, corrosion resistance, heat resistance | -40 | 150 | -25~135 |
Dimensions
| OD | L | A | A1 | F | T | MxL |
| 40 | 70 | 74 | 43 | 100 | 18 | M8x30 |
| 50 | 80 | 84 | 48 | 114 | 18 | M10x35 |
| 63 | 90 | 97 | 54 | 127 | 18 | M10x35 |
| 75 | 100 | 110 | 61 | 144 | 18 | M10x35 |
| 90 | 100 | 124 | 70 | 156 | 20 | M10x35 |
| 110 | 100 | 144 | 80 | 178 | 20 | M10x35 |
| 125 | 110 | 160 | 90 | 197 | 20 | M12x35 |
| 140 | 125 | 176 | 97 | 212 | 20 | M12x35 |
| 160 | 125 | 198 | 109 | 233 | 20 | M12x35 |
| 200 | 140 | 240 | 131 | 282 | 20 | M14x40 |
| 225 | 140 | 266 | 144 | 307 | 20 | M14x40 |
| 250 | 140 | 291 | 156 | 334 | 20 | M14x40 |
| 315 | 140 | 356 | 189 | 400 | 20 | M14x40 |
